ESPRITE®
Robe, the recognised leader in moving light technology, has made another major leap in innovation. The new ESPRITE® Profile LED automated luminaire has a fast-change, low-cost, transferable light engine ingeniously solving the problem of performance longevity for those preferring the higher brightness of white source LEDs as an obvious replacement for their aging stock of discharge workhorses.
Light source
TE™ 650W White LED TRANSFERABLE ENGINE
Light output
up to 34.000 lm, 85.000 lx @ 5m, Cpulse™ special flicker free management for HD and UHD cameras, ready for 8K and 16K
Zoom range
5.5° - 50°
Effects
Static and rotating gobo wheel, Animation wheel, Framing shutters, Prism
With our unique, ground-breaking TRANSFERABLE ENGINE technology, you have a choice of engines. The TE™ 650W HP White LED Engine (HP – High Performance), producing the highest output possible, or the TE™ 650W HCF White LED Engine (HCF – High Colour Fidelity) for those requiring exceptional colour quality. Now you can fit either engine within the same fixture, without alignment or warranty issues, within five minutes! Without the expense, and complication of needing to have separate luminaires with differing sources, TRANSFERABLE ENGINES give you the right engine, in the right fixture, at the right time!
The revolutionary self-referencing, data capturing engines are all designed, developed and manufactured within our own factory (Patents pending). Performance has not been compromised, with the TE™ 650W HP White 6.700 K LED Engine producing a piercing 34.000 lm and the TE™ 650W HCF White 6.000 K LED Engine 24.000 lm with its exceptionally high inherent CRI of 96. The L70/B50 ratings of 50.000 hours, means longevity is assured.
This is enhanced by our legendary precision optics to produce crystal clear white light. The comprehensive feature set includes: Flat field CMY mixing; variable CTO; remotely selectable CRI 70/80/90 (HP Engine); two fast colour wheels; rotating and static gobo wheels; 6-facet rotating prism; 1° soft edge and 5° even wash frosts; an animation wheel and spectacular multi-colour effects. Quick, accurate, easy framing is provided via our patented fast framing shutter module with individual blade control and +/-60° rotation capability for extra fine control. The ESPRITE® Profile by design removes any airflow over the optics, resulting in reduced residue deposits thus extending periods between cleaning.
Furthermore, the unique Hot-Spot feature allows you to move from a flat field beam to a 6:1 ratio hot-spot beam giving uniform intensity when overlaying beam edges to create smooth washes of light. The Cpulse™ flicker-free management system operates beautifully with the latest HD and UHD camera systems. ChromaTint™ gives full green/magenta content control, with L3™ Low Light Linearity dimming for ultra-smooth fade to black for seamless integration into traditional lighting rigs.
Technical Specification
Source
Light source type: TE™ 650W HP White LED Engine (Patented)
- HP - High Performance Engine for maximum light output and optimal colour characteristics
- LED Engine output: 55.000 lm
- Fixture total lumen output:
- 34.000 lm (integrating sphere)
- 27.000 lm (goniophotometer)
- Colour temperature output: 6.700 K
- CRI: 70, remotely selectable filters for CRI 80 and CRI 90
- Illuminance: 85.000 lx @ 5 m
Light source type: TE™ 650W HCF White LED Engine (Patented)
- HCF - High Colour Fidelity Engine for the best light quality and colour rendition
- LED Engine output: 37.500 lm
- Fixture total lumen output:
- 22.800 lm (integrating sphere)
- 18.300 lm (goniophotometer)
- Colour temperature output: 6.000 K
- CRI: 96, TLCI: 97, TM-30-18 Rf: 92, TM-30-18 Rg: 99
- Illuminance: 59.000 lx @ 5 m
Light source type: TE™ 650W TGW White LED Engine (Patented):
- TGW - Simulates the comforting warmth of tungsten lighting
- LED Engine output: 30.250 lm
- Fixture total lumen output:
- 19.500 lm (integrating sphere)
- 15.700 lm (goniophotometer)
- Colour temperature output: 3.200 K
- CRI: 97, TLCI: 97, TM-30-18 Rf: 93, TM-30-18 Rg: 102
- Illuminance: 50.000 lx @ 5 m
LED life expectancy: min. 50.000 hours
Typical lumen maintenance: L70/B50 @ 50.000 hours
Light source warranty: 4 years or 20.000 hours
Optical system
Robe’s proprietary optical design
High-efficiency 13-lens zoom optical system, ratio: 9:1
Zoom range: 5.5° - 50°
Output lens diameter: 150 mm
Dynamic Effects and Features
Cyan: 0 - 100%
Magenta: 0 - 100%
Yellow: 0 - 100%
Variable CTO: 3.000K - 6.700K
ChromaTint™ - Patented plus / minus green correction function
Colour Wheel 1: 5 fixed dichroic colours + white
Colour Wheel 2: 5 fixed dichroic colours + white
Framing shutters: Patented Plano4™ framing shutters module with 4 individually positionable blades plus rotation of the complete frame system + - 60°
Rotating gobo wheel: 7 rotating, indexable and replaceable breakup and aerial gobos + open, patented slot & lock system
Static gobo wheel: 9 static and replaceable gobos + open
Animation wheel: Aluminium animation wheel, used alone or in combination with gobos, rotating in both directions at variable speed
Prism: 6-facet prism rotating in both directions at variable speed
Iris: Motorized, stepless, pulse effects up to 3 Hz
Frosts: MagFrost™ - magnetic paddle fast change system providing exchangeable frosts containing as standard a very light 1° for instant softening of the projected gobo or framing shutters, and a medium 5° for even wash, both specifically selected for theatre and TV use
Hot-Spot: from flat field to 6:1 hot-spot (optional)
Motorized zoom and focus
Electronic strobe effect with variable speed up to 20 Hz
High resolution electronic dimming: 0 - 100%
L3™ - (Low Light Linearity) Imperceptible 18 bit dimming for ultra smooth fade to black
Cpulse™ special flicker free management for HD and UHD cameras, ready for 8K and 16K
AirLOC™ (Less Optical Cleaning) technology greatly reduces the level of airborne particles drawn over the optical elements. This increases the overall performance, light quality and time between routine cleaning and maintenance.
Control and programming
Setting & Addressing: ROBE Navigation System 2 (RNS2)
Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in analyser for easy fault finding
Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2, sACN
REAP™ - Robe Ethernet Access Portal
Wireless CRMX™ technology from Lumen Radio - on request
Epass™: Ethernet pass through switch which sustains Ethernet integrity, when the fixture has no power, to automatically maintain network connectivity - on request
DMX Protocol modes: 4
Control channels: 49, 42, 50, 43
Pan & Tilt resolution: 16 bit
CMY & CTO: 8 bit
+ - Green correction: 8 bit
Colour wheel positioning: 8 or 16 bit
Framing shutters module movement & rotation: 8 bit
Rotating gobo wheel positioning: 8 bit
Gobo indexing & rotation: 8 or 16 bit
Static gobo wheel positioning: 8 bit
Animation wheel: 8 bit
Animation wheel rotation: 8 bit
Iris: 8 or 16 bit
Frost: 8 bit
Zoom: 8 or 16 bit
Focus: 8 or 16 bit
Dimmer: 8 or 16 bit (internal 18 bit)
Movement
Pan movement: 540°
Tilt movement: 265°
Movement control: Standard and Speed
EMS™: Electronic Motion Stabilizer system for Pan & Tilt reducing beam deviation caused by truss movement or vibration (Patented)
Automatic Pan & Tilt position correction
Rotating gobos
7x rotating glass gobos
Outside diameter: 26.8 mm
Image diameter: 23.5 mm
Thickness: 1.1 mm
Max. thickness: 3.5 mm
High temperature borofloat or better glass
Patented slot & lock system for easy replacement of gobos
Static gobos
9x static glass gobos
Outside diameter: 26.8 mm
Image diameter: 23.5 mm
Thickness: 1.1 mm
Max. thickness: 3.5 mm
High temperature borofloat or better glass
Effect wheel
Single animation wheel
Material: Aluminium
Can be used alone or in combination with rotating gobos
Rotating in both directions at variable speed
Framing shutters system
Patented Plano4™ framing shutters module
Shutters: 4 Blades, each with separate movement and +- 25° rotation control
Movement: Smooth with variable speed, ultrafast blade movements for creating mid-air effects
Rotation: +- 60° of the complete framing system
Thermal specification
Maximum ambient temperature: 45°C (113°F)
Maximum surface temperature: 80°C (176°F)
Minimum operating temperature: -5°C (23°F)
Total heat dissipation: max. 2430 BTU/h (calculated)
Noise Levels
Sound pressure level:
27 dB(A) at 1 m (quiet mode)
42 dB(A) at 1 m (auto mode)
Sound power level:
35 dB(A) (quiet mode)
50 dB(A) (auto mode)
Electrical specification and connections
Power supply: Electronic auto-ranging
Input voltage range: 100-240 V, 50/60 Hz
Power consumption:
Standard mode max. 870 W at 230 V / 50 Hz
High-power mode max. 950 W at 230 V / 50 Hz
Power in connector: Neutrik powerCON TRUE1
DMX and RDM data in/out: Locking 3-pin & 5-pin XLR
Ethernet port in: RJ45
Ethernet port in/out: RJ45 for Embedded Epass™ switch 10/100 Mbps - on request
USB connector (series A) for lightmaster purposes
Approvals
CE Compliant
cETLus Compliant
Mechanical specification
Height: 733 mm (28.9") - head in vertical position
Width: 443 mm (17.4")
Depth: 264 mm (10.4") - head in vertical position
Weight: 28.2 kg (62.2 lbs)
Ingress protection rating: IP20
Rigging
Mounting positions: Horizontally or vertically
Universal operating position
Mounting points: 5 pairs of 1/4-turn locking points
2x Omega adaptors with 1/4-turn quick locks
Safety cable attachment point
Pan & Tilt transport locks
Included items
User Manual
Omega Adaptor CL-regular 2 pcs : 10980033
Power cord including powerCON TRUE1 In connector
Optional accessories
ESPRITE TE™ 650W HP White LED Engine: 14080066
ESPRITE TE™ 650W HCF White LED Engine: 14080071
ESPRITE TE™ 650W TGW White LED Engine: 14080079
Frost 0.5° (exchange) assembled: 10980583
Frost 10° (exchange) assembled: 10980497
Frost 20° (exchange) assembled: 10980574
Frost 30° (exchange) assembled: 10980584
FS BMFL/Esprite Handles - 2 pcs in box: 10980233
Hot-Spot lens in gobo holder: 10980483
Gel frame adaptor: 10980463
Gel frame: 10980464
Doughty Trigger Clamp: 17030386
Omega Adaptor Tall CL-regular 2 pcs in box: 10980501
Safety wire 36 kg: 99011963
Single Top Loader Case: 10120254
Dual Top Loader Case: 10120255
Foam Shell: 20020357
Top Hat: 10980568
Legal
ESPRITE® is a Trademark of Robe lighting s. r. o.
ESPRITE® is patented by Robe lighting s. r. o. and protected by one or more pending or issued patents
Gobos&Colours
Rotating Gobo Wheel
15020372
15020373
15020374
15020375
15020376
15020377
15040011
Static Gobo Wheel
15020378
15020379
15020380
15020381
15020382
15020383
15020384
15020385
15020386
Colour Wheel 1
14070463
14070464
14070465
14070466
14070467
Colour Wheel 2
14070473-6
14070469
14070470
14070471
14070472
Animation Wheel
11020208-02
